uWAVE underwater acoustic modem

uWAVE is the world smallest underwater acoustic digital modem, which allows to communicate up to 20 subscribers in area 1000 x 1000 meters with both transparent channel and predefined code messages/telemetry transmission.
Extremely small size, low power consumption and simplicity of usage make uWAVE an ideal solution for AUV control as well as data transmission, where dimensions and wight are the bottleneck.

Key features:

  • Extremely small size and weight
  • Can be applied in underwater wireless sensor networks
  • Reliable data transmission with 78 bit/s
  • Operating range up to 1000 m
  • Subscribers code division
  • Propagation time measurement
  • Reliable and noise-immune technology of digital broadband acoustic communication
  • Low power consumption (Rx/Tx) 0.33/6 W
  • Open configuration protocol
  • Built-in depth/temperature sensor


To order one or several devices please click the button below

Technical specification:

Dimensions 40 х 45 mm
Weight (dry) 0.16 kg
Depth rating 300 m
Max operating range 1000 m
Frequency band 10-30 kHz
BER 10^-6
Start-up time 100 ms
SNR -2 dB
Wire length 1 m
Max relative velocity +/- 1 mps
Operating temperature range -5..50 ˚С
Data transmission rate 78 bps
Power consumption Rx/Tx 0.33/6 W
Power supply 12 V
Data lines voltage 0..3.3 V
Protocol NMEA 0183 PUWV
Subscribers code division
20 code channels
Command mode
16 predefined messages (9 for user applications)
